Massey Ferguson 1417

Production: 2003 - 2005

Production
Distributor:	Massey Ferguson
Manufacturer:	Iseki
Type:	Compact Utility tractor
Factory:	Matsuyama, Japan

Massey Ferguson 1417 Power
Engine (gross):	16.6 hp 12.4 kW
Gear PTO (claimed):	13.3 hp 9.9 kW
Hydro PTO (claimed):	12.6 hp 9.4 kW

Mechanical
Chassis:	4x4 MFWD 4WD
Steering:	power
Brakes:	dry shoe
Cab:	Two-post fixed ROPS.
Transmissions:	6-speed gear
hydrostatic

Hydraulics
Type:	open center
Pressure:	1990 psi 137.2 bar
Pump flow:	4.8 gpm 18.2 lpm
Total flow:	6.3 gpm 23.8 lpm
Steering flow:	1.5 gpm 5.7 lpm

Tractor hitch
Rear Type:	I
Control:	position and response control
Rear lift (at ends):	1058 lbs 479 kg
Rear Arms:	fixed link ends with turn-buckle stabilizers

Power Take-off (PTO)
Gear Rear PTO:	transmission
Hydro Rear PTO:	live
Rear RPM:	540
Mid PTO:	standard
Mid RPM:	2000

1417 Serial Numbers
2002:	LA0001
2003:	MA0001
2004:	NA0001
2005:	P0001

Electrical
Ground:	negative
Battery volts:	12

Engine Detail
Iseki
diesel
3-cylinder
liquid-cooled
Displacement:	56.6 ci 0.9 L
Emissions:	Tier 2
Power (gross):	16.6 hp 12.4 kW
Fuel system:	indirect injection
Rated RPM:	2500
Starter volts:	12

Dimensions
Wheelbase:	56.1 inches 142 cm
Length:	100.2 inches 254 cm
Width:	39 inches 99 cm *Minimum width.
Height (ROPS):	74.4 inches 188 cm
Weight:	1422 lbs 645 kg
Front tread:	29.5 inches 74 cm
Rear tread:	30.3 to 37.4 inches 76 to 94 cm
