LS PS90

Production
Manufacturer:	LS
Type:	Utility tractor

LS PS90 Power
Engine:	87 hp 64.9 kW
PTO (claimed):	77 hp 57.4 kW

Mechanical
Chassis:	4x4 MFWD 4WD
Steering:	hydrostatic power
Cab:	ROPS. Cab optional with air-conditioning.
Transmissions:	20-speed synchronized shuttle
40-speed power shuttle

Hydraulics
Rear valves:	3
Front valves:	2
ROPS Pump flow:	10.8 gpm 40.9 lpm
Cab Pump flow:	14.8 gpm 56.0 lpm
Steering flow:	6 gpm 22.7 lpm

Tractor hitch
Rear Type:	II
Control:	position and draft control
Rear lift:	6173 lbs 2800 kg

Power Take-off (PTO)
Rear PTO:	independent
Rear RPM:	540/750/1000

Electrical
Ground:	negative
Battery volts:	12

Engine Detail
FPT F5C
turbocharged intercooled diesel
4-cylinder
liquid-cooled
Displacement:	195 ci 3.2 L
Bore/Stroke:	3.898x4.094 inches 99 x 104 mm
Emissions:	Tier 3
Power:	87 hp 64.9 kW
Air cleaner:	dry
Rated RPM:	2300
Starter:	electric
Starter volts:	12

Dimensions
Wheelbase:	86.6 inches 219 cm
Length:	157.1 inches 399 cm
Width:	79.5 inches 201 cm
Height (ROPS):	105.4 inches 267 cm
Height (cab):	103.5 inches 262 cm
ROPS Weight:	6411 lbs 2908 kg
Cab Weight:	7015 lbs 3182 kg
