Honda HF2315

Production: 2004 - 2019

PDF

• Download Honda HF2315 Operator's Manual
• Download Honda HF2315 Original Instruction
• Download Honda HF2315HME User Manual

Production
Manufacturer	Honda
Type	Lawn tractor

Variants
HF2315S	gear
HF2315H	hydrostatic

Mechanical
Chassis	4x2 2WD
Steering	manual
Cab	Open operator station.

Power Take-off (PTO)
Mid PTO	independent

Electrical
Ground	negative
Battery volts	12
Battery AH	24

Engine Detail
Honda GCV520
gasoline
2-cylinder
air-cooled vertical-shaft V-twin
Displacement	529 cc 32.3 ci
Bore/Stroke	3.03x2.24 inches 77 x 57 mm
Power	14 hp 10.4 kW
Rated RPM	2800
Starter	electric
Starter volts	12

Dimensions
Wheelbase	45.3 inches 115 cm
Length	73.6 inches 186 cm
97.6 inches (with collector) 247 cm
Height (steering wheel)	43.7 inches 110 cm
Height (hood)	38.6 inches 98 cm
Gear Weight	463 lbs 210 kg
Hydro Weight	470 lbs 213 kg
