Toro 4 HP 57000

Production: 1967

Production
Manufacturer	Toro
Type	Lawn tractor
Original price	$280 (1967 )

Mechanical
Chassis	4x2 2WD
Steering	manual
Cab	Open operator station.

Power Take-off (PTO)
Rear PTO	independent

4 HP Serial Numbers
1967	7000001

Engine Detail
Briggs & Stratton 100902
gasoline
1-cylinder
air-cooled vertical-shaft
Displacement	170 cc 10.4 ci
Bore/Stroke	2.50x2.18 inches 64 x 55 mm
Power (gross)	4 hp 3.0 kW
Starter type	recoil

Transmission
Type	belt-driven gear
Gears	2 forward and 1 reverse
