Massey Ferguson 2918H
Type: Garden Tractors
Contents:
Production | |
| Distributor | Massey Ferguson |
| Manufacturer | Simplicity |
| Type | Garden tractor |
| Factory | Port Washington, Wisconsin, USA |
Variants | |
| similar Simplicity model | |
Mechanical | |
| Chassis | 4x2 2WD |
| Steering | power |
| Cab | Open operator station. Vinyl snow cab optional. |
Tractor hitch | |
| Rear Type | 0 OptOptional |
2918H Serial Numbers | |
| Location: | Serial number on the left side of the tractor frame, above the front axle. |
Electrical | |
| Ground | negative |
| Battery volts | 12 |
Engine Detail | |
| Briggs & Stratton Vanguard | |
| gasoline | |
| 2-cylinder | |
| air-cooled horizontal-shaftV-Twin | |
| Displacement | 569 cc 34.75 ci |
| Bore/Stroke | 2.83x2.75 inches 72 x 70 mm |
| Power (gross) | 18 hp 13.4 kW |
| Rated RPM | 3600 |
| Starter | electric |
| Starter volts | 12 |
Transmission | |
| Type | shaft-driven hydrostatic |
| Gears | infinite forward and reverse |
| Oil capacity | 6 qts 5.7 L |
Dimensions | |
| Wheelbase | 51 inches 129 cm |
| Length | 78 inches 198 cm |
| Width | 38.25 inches 97 cm |
| Height (steering wheel) | 47 inches 119 cm |
| Weight | 825 lbs 374 kg |
| Rear axle | 5-bolt flange |
