Production | |
Manufacturer | John Deere |
Type | Lawn tractor |
Factory | Horicon, Wisconsin, USA |
Original price | $3,099 (1997 42 ) |
Original price | $3,199 (1997 46 ) |
Variants | |
lawn tractor | |
rear-discharge mower |
Mechanical | |
Chassis | 4x2 2WD |
Steering | manual |
Brakes | disc |
Cab | Open operator station. |
Power Take-off (PTO) | |
Mid PTO | independent |
Clutch | manual |
LT166 Serial Numbers | |
1998 | 010001 |
1999 | 045001 |
2000 | 085001 |
2001 | 125001 |
LT166 Serial Location | |
On tractor body, below and in front of seat. |
Electrical | |
Ground | negative |
Battery CCA | 160 |
Battery volts | 12 |
Engine Detail | |
Briggs & Stratton 303777 | |
gasoline | |
2-cylinder | |
air-cooled vertical-shaft V-Twin | |
Displacement | 480 cc 29.3 ci |
Bore/Stroke | 2.68x2.60 inches 68 x 66 mm |
Power | 16 hp 11.9 kW |
Starter | electric |
Starter volts | 12 |
Sparkplug gap | 0.040 inches 1.016 mm |
Transmission | |
Transmission | Tuff-Torq K51 |
Type | belt-driven hydrostatic |
Gears | infinite forward and reverse |
Oil change | sealed unit, owner service is not recommended |
Hydrostatic transmission with two right-side foot pedals and right-side brake. Free-wheeling lever at rear of tractor. |
Dimensions | |
Wheelbase | 46.3 inches 117 cm |
Length | 67.91 inches 172 cm |
Width | 36 inches 91 cm |
Height | 40.6 inches 103 cm |
