John Deere L100

Production: 2003 - 2005

Production
Manufacturer	John Deere
Type	Lawn tractor
Original price	$1,499 (2005 )

Mechanical
Chassis	4x2 2WD
Steering	manual
Brakes	disc
Cab	Open operator station.

Power Take-off (PTO)
Mid PTO	independent
Clutch	mechanical

L100 Serial Numbers
Location:	On frame above left rear wheel.
2003	010001
2004	080001
2005	140001

Electrical
Ground	negative
Charging amps	9
Battery volts	12
Battery Group	BCI Group U1

Engine Detail
Briggs & Stratton 31F707
gasoline
1-cylinder
air-cooled vertical shaft
Displacement	501 cc 30.6 ci
Bore/Stroke	3.57x3.06 inches 91 x 78 mm
Power	17 hp 12.7 kW
Air cleaner	paper and foam
Starter	electric
Starter volts	12
Sparkplug gap	0.030 inches 0.762 mm

Transmission
Transmission	Dana 4360
Type	belt-driven gear
Gears	5 forward and 1 reverse
Oil change	sealed unit, service not recommended

Dimensions
Length	60 inches 152 cm
Width	36 inches 91 cm
Height	38.6 inches 98 cm
Weight	462 lbs 209 kg
