John Deere 430

Production: 1984 - 1992

Production
Manufacturer	John Deere
Type	Garden tractor
Factory	Horicon, Wisconsin, USA
Original price	$9,500 (1992 )

Mechanical
Chassis	4x2 2WD
Differential lock	mechanical rear
Steering	power
Brakes	differential mechanical drum
Cab	Open operator station.

Capacity
Fuel	6.5 gal 24.6 L
Hydraulic system	1.875 gal 7.1 L

Hydraulics
Capacity	1.875 gal 7.1 L
Valves	3

Tractor hitch
Rear Type	0 OptOptional
Rear lift	640 lbs 290 kg

Power Take-off (PTO)
Rear PTO	independent OptOptional
Clutch	electric
Rear RPM	2000
Front PTO	independent
Clutch	electric
Front RPM	3400

430 Serial Numbers
Location:	Serial number plate below the steering column on the John Deere 430.
1984	M00430X285001
1985	M00430X315001
1986	M00430X360001
1987	M00430X420001
1988	M00430X475001
1989	M00430X595001
1990	M00430X010001
1991	M00430X100001
1992	M00430X110001

Electrical
Ground	negative
Charging system	alternator
Charging amps	35
Battery volts	12

Engine Detail
Yanmar 3TNA72UJ
diesel
3-cylinder
liquid-cooled horizontal-shaft inline
Displacement	885 cc 54 ci
Bore/Stroke	2.83x2.83 inches 72 x 72 mm
Power	20 hp 14.9 kW
Air cleaner	dry
Pre-heating	glow plugs
Idle RPM	1300-3400
Starter volts	12
Coolant capacity	4 qts 3.8 L

Transmission
Transmission	Sundstrand 90
Type	shaft-driven hydrostatic
Gears	infinite forward and reverse (2-range)
Oil capacity	7.5 qts 7.1 L
Oil change	200 h

Dimensions
Wheelbase	52 inches 132 cm
Length	84 inches 213 cm
Width	51.5 inches 130 cm
Height	48.5 inches 123 cm
Weight	1170 lbs 530 kg
Rear axle	Flange: 1.2 inch diameter 30 mm
