John Deere 100

Production: 1975 - 1978

Production
Manufacturer	John Deere
Type	Lawn tractor
Factory	Horicon, Wisconsin, USA

Mechanical
Chassis	4x2 2WD
Steering	manual
Cab	Open operator station.

Power Take-off (PTO)
Mid PTO	independent
Clutch	mechanical idler pulley

100 Serial Numbers
Location:	Serial number plate below the steering column on the John Deere 100.
1975	30001
1976	55001
1977	70001
1978	80001

Electrical
Ground	negative
Charging system	alternator
Battery CCA	135
Battery volts	12
Battery Group	U1

Engine Detail
Briggs & Stratton 190707
gasoline
1-cylinder
air-cooled vertical-shaft
Displacement	318 cc 19.44 ci
Bore/Stroke	3.00x2.75 inches 76 x 70 mm
Power	8 hp 6.0 kW
Rated RPM	3600
Starter volts	12
Sparkplug	Champion J-8
Sparkplug gap	0.030 inches 0.762 mm
Point gap	0.020 inches 0.508 mm

Transmission
Transmission	Peerless 1200
Type	belt-driven gear
Gears	3 forward and 1 reverse
Oil capacity	1.5 qts 1.4 L
Oil type	80W90 GL5

Dimensions
Wheelbase	42.5 inches 107 cm
Length	59 inches 149 cm
Width	30.7 inches 77 cm
Height	37 inches 93 cm
Weight	390 lbs 176 kg
