Production | |
Manufacturer: | Bolens |
Type: | Garden tractor |
Factory: | Port Washington, Wisconsin, USA |
Mechanical | |
Chassis: | 4x2 2WD |
Steering: | manual |
Brakes: | disc |
Cab: | Open operator station. |
Transmission: | hydrostatic |
Capacity | |
Fuel: | 5 gal 18.9 L |
Power Take-off (PTO) | |
Mid PTO: | independent |
Clutch: | electric |
13014 Serial Numbers | |
Location: | Serial number tag on the rear fender, under the tractor seat, on the left side. |
Electrical | |
Ground: | negative |
Engine Detail | |
Briggs & Stratton 294777 | |
gasoline | |
2-cylinder | |
air-cooled vertical-shaft horizontally-opposed | |
Displacement: | 480 cc 29.3 ci |
Bore/Stroke: | 2.68x2.60 inches 68 x 66 mm |
Power: | 14 hp 10.4 kW |
Starter: | electric |
Starter volts: | 12 |
Oil capacity: | 1.75 qts 1.7 L |
Transmission | |
Transmission: | Eaton 751 |
Type: | belt-driven hydrostatic |
Gears: | infinite forward and reverse |
Dimensions | |
Wheelbase: | 45 inches 114 cm |
Length: | 69 inches 175 cm |
Width: | 34.5 inches 87 cm |
Height: | 42 inches 106 cm |
