Gravely 8199

Production: 1980 - 1985

Production
Manufacturer	Gravely
Type	Garden tractor

Mechanical
Chassis	4x2 2WD
Steering	manual
Cab	Open operator station.

Hydraulics
Type	open center
Pressure	1200 psi 82.7 bar
Pump flow	1.7 gpm 6.4 lpm

Power Take-off (PTO)
Mid PTO	independent
Clutch	mechanical
Mid RPM	1000

Engine Detail
Onan B48G
gasoline
2-cylinder
air-cooled horizontal-shaft opposed-twin
Displacement	781 cc 47.7 ci
Bore/Stroke	3.25x2.875 inches 83 x 73 mm
Power (gross)	19.9 hp 14.8 kW
Rated RPM	3600
Starter volts	12

Transmission
Type	shaft-driven gear
Gears	8 forward and 4 reverse
Oil capacity	6 qts 5.7 L
Oil type	10W-40 SC

Dimensions
Wheelbase	52 inches 132 cm
Length	83 inches 210 cm
Width	43 inches 109 cm
Height	44.125 inches 112 cm
Shiping weight	935 lbs 424 kg
Ground clearance	7 inches 17 cm
