Kubota STV32

Production: 2006 - 2014

Production
Manufacturer:	Kubota
Type:	Compact Utility tractor

Kubota STV32 Power
Engine (gross):	32.3 hp 24.1 kW
Engine (net):	30.6 hp 22.8 kW
PTO (claimed):	23.7 hp 17.7 kW

Mechanical
Chassis:	4x4 MFWD 4WD
Differential lock:	mechanical rear
Steering:	power
Brakes:	wet disc
Cab:	Two-post ROPS. Cab optional.
Transmission:	hydrostatic

Hydraulics
Pressure:	2461 psi 169.7 bar
Pump flow:	6.1 gpm 23.1 lpm

Tractor hitch
Rear Type:	I
Control:	position control
Rear lift (at ends):	2535 lbs 1149 kg

Power Take-off (PTO)
Rear PTO:	independent
Rear RPM:	540 (1.375)
Engine RPM:	540@2670 800@2717
Mid RPM:	2500
Engine RPM:	2500@2734

Electrical
Ground:	negative
Charging system:	alternator
Battery volts:	12

Engine Detail
Kubota D1503M
diesel
3-cylinder
liquid-cooled
Displacement:	91.5 ci 1.5 L
Bore/Stroke:	3.268x3.638 inches 83 x 92 mm
Power (gross):	32.3 hp 24.1 kW
Rated Power (ECE R24):	30.6 hp 22.8 kW
Rated RPM:	2700
Starter:	electric
Starter volts:	12

Transmission
Type:	hydrostatic
Gears:	infinite (3-range) forward and reverse

Dimensions
Wheelbase:	63.4 inches 161 cm
Length:	105.5 inches 267 cm
Width:	48 inches 121 cm *Minimum width with R1 tires.
Height (ROPS):	92.5 inches 234 cm
Height (cab):	85 inches 215 cm
ROPS Weight:	2150 lbs 975 kg
Cab Weight:	2502 lbs 1134 kg
Ground clearance:	9.3 inches 23 cm
Front tread:	40.6 inches 103 cm
Rear tread:	37.4 to 42.1 inches 94 to 106 cm
