Kubota MZ505
Type: Utility Tractors
Contents:
Production | |
| Manufacturer: | Kubota |
| Type: | Utility tractor |
Kubota MZ505 Power | |
| Engine: | 49.3 hp 36.8 kW |
Mechanical | |
| Chassis: | 4x4 MFWD 4WD |
| Steering: | power |
| Brakes: | mechanical wet disc |
| Cab: | Cab standard. |
| Transmission: | 24-speed |
Tractor hitch | |
| Rear Type: | II/I |
| Control: | position and draft control |
Power Take-off (PTO) | |
| Rear RPM: | 540 (1.375)*Three-speed PTO shift with available ground speed or reverse 540 |
| Engine RPM: | 544@2400 764@2400 1080@2400 |
Engine Detail | |
| Kubota V3600IDI | |
| diesel | |
| 4-cylinder | |
| liquid-cooled | |
| Displacement: | 220.9 ci 3.6 L |
| Bore/Stroke: | 3.86x4.72 inches 98 x 120 mm |
| Power: | 49.3 hp 36.8 kW |
| Rated RPM: | 2400 |
| Starter type: | electric |
Transmission | |
| Gears: | 24 forward and reverse |
| Clutch: | electro-hydraulic wet disc |
| Eight gears (1-8) in three ranges (creeper, low, and high) with left-hand shuttle shift. | |
Dimensions | |
| Wheelbase: | 80.7 inches 204 cm |
| Length: | 142.7 inches 362 cm |
| Width: | 61.6 inches 156 cm |
| Height (cab): | 95.1 inches 241 cm |
| Weight: | 5225 lbs 2370 kg |
| Ground clearance: | 15 inches 38 cm |
| Front tread: | 51.2 inches 130 cm |
| Rear tread: | 48 to 63.4 inches 121 to 161 cm |
