Kubota MX5800

Production: 2015

Production
Manufacturer:	Kubota
Type:	Utility tractor
Original price:	$29,905 (2015 )

Kubota MX5800 Power
Engine (gross):	61.4 hp 45.8 kW
Engine (net):	57.5 hp 42.9 kW
PTO (claimed):	50.2 hp 37.4 kW

Mechanical
Chassis:	4x4 MFWD 4WD
Differential lock:	mechanical rear
Steering:	hydrostatic power
Brakes:	mechanical wet disc
Cab:	Two-post foldable ROPS.
Transmission:	hydrostatic

Capacity
Hydraulic system:	11.6 gal 43.9 L

Hydraulics
Type:	open center
Capacity:	11.6 gal 43.9 L
Valves:	1 to 3
Pump flow:	9.5 gpm 36.0 lpm
Total flow:	14.4 gpm 54.5 lpm
Steering flow:	4.9 gpm 18.5 lpm

Tractor hitch
Rear Type:	II/I
Control:	position control
draft control*Optional
Rear lift (at ends):	2870 lbs 1301 kg
Rear lift (at 24"/610mm):	2310 lbs 1047 kg
Rear Arms:	telescoping low links and stabilizers

Power Take-off (PTO)
Rear PTO:	independent
Clutch:	electro-hydraulic wet disc
Rear RPM:	540 (1.375)
Engine RPM:	540@2659

Electrical
Ground:	negative
Charging system:	alternator
Charging amps:	45
Battery CCA:	600
Battery volts:	12

Engine Detail
Kubota V2403CR-T
turbocharged diesel
4-cylinder
liquid-cooled
Displacement:	148.6 ci 2.4 L
Emissions:	Tier 4
Emission control:	diesel particular filter (DPF)
Power (gross):	61.4 hp 45.8 kW
Fuel system:	direct injection
Air cleaner:	dual dry element
Rated RPM:	2700
Starter:	electric
Starter volts:	12
Oil capacity:	9.9 qts 9.4 L
Coolant capacity:	6.9 qts 6.5 L

Transmission
Type:	hydrostatic
Gears:	infinite (3-range) forward and reverse

Dimensions
Wheelbase:	74.6 inches 189 cm
Length:	125.2 inches 318 cm
Width:	69.7 inches 177 cm *Minimum
Height (ROPS):	95.7 inches 243 cm
Weight:	3734 lbs 1693 kg
Ground clearance:	15.2 inches 38 cm
Front tread:	52.2 inches 132 cm
Rear tread:	54.1 to 58.7 inches 137 to 149 cm
