Kubota M7950HC

Production: 1986 - 1994

Production
Manufacturer:	Kubota
Type:	High-Clearance tractor
Factory:	Japan

Variants

2WD

4WD

wide-tread

mudder

high-crop

Kubota M7950HC Power
Engine (net):	81 hp 60.4 kW
PTO (claimed):	75.44 hp 56.3 kW

Mechanical
Chassis:	4x4 MFWD 4WD
Steering:	hydrostatic power
Brakes:	differential hydraulic wet disc
Cab:	Four-post ROPS canopy. Cab optional.
Transmission:	16-speed

Capacity
Fuel:	26.4 gal 99.9 L
Hydraulic system:	13.2 gal 50.0 L

Hydraulics
Type:	open center
Capacity:	13.2 gal 50.0 L
Pressure:	2630 psi 181.3 bar
Valves:	1 or 2
Total flow:	11 gpm 41.6 lpm

Tractor hitch
Rear Type:	II
Rear lift (at ends):	4,848 lbs 2199 kg
Rear lift (at 24"/610mm):	4,475 lbs 2029 kg

Power Take-off (PTO)
Rear PTO:	independent
Rear RPM:	540/1000

Electrical
Charging system:	alternator
Charging amps:	65 (with cab)
Battery volts:	12
Battery AH:	300

Engine Detail
Kubota V4300
diesel
4-cylinder
liquid-cooled
Displacement:	261.9 ci 4.3 L
Bore/Stroke:	4.29x4.53 inches 109 x 115 mm
Air cleaner:	dry element
Compression:	17:1
Rated RPM:	2400
Starter volts:	12
Oil capacity:	13.9 qts 13.2 L
Coolant capacity:	14.4 qts 13.6 L

Transmission
Gears:	16 forward and 4 reverse

Dimensions
Wheelbase:	87.6 inches 222 cm
Ground clearance:	24 inches 60 cm
Front tread:	56 to 80 inches 142 to 203 cm
Rear tread:	76 to 80 inches 193 to 203 cm
