Kubota M4970

Production: 1986 - 1988

Production
Manufacturer:	Kubota
Type:	Utility tractor

Kubota M4970 Power
Engine:	49.5 hp 36.9 kW
PTO (claimed):	47.5 hp 35.4 kW

Mechanical
Chassis:	4x4 MFWD 4WD
Transmission:	16-speed

Hydraulics
Pump flow:	9.25 gpm 35.0 lpm

Tractor hitch
Rear Type:	JISII/I
Rear lift:	4189 lbs 1900 kg

Power Take-off (PTO)
Rear RPM:	540/1000 (1.375)
Engine RPM:	540@2194 1000@2530

Electrical
Ground:	negative
Battery volts:	12

Engine Detail
Kubota S2802
diesel
6-cylinder
liquid-cooled
Displacement:	170.3 ci 2.8 L
Bore/Stroke:	3.35x3.23 inches 85 x 82 mm
Power:	49.5 hp 36.9 kW
Rated RPM:	2600
Torque:	129 lb-ft 174.9 Nm
Torque RPM:	1600
Starter:	electric
Starter volts:	12
Oil capacity:	15.5 qts 14.7 L
Coolant capacity:	8.7 qts 8.2 L

Transmission
Gears:	16 forward and 4 reverse

Dimensions
Wheelbase:	83.1 inches 211 cm
Length:	143.5 inches 364 cm
Width:	68.9 inches 175 cm
Height (ROPS):	95.3 inches 242 cm
Height (exhaust):	89.4 inches 227 cm
Weight:	5379 lbs 2439 kg
Ground clearance:	14.4 inches 36 cm
Front tread:	48 to 55.1 inches 121 to 139 cm
Rear tread:	48 to 75.6 inches 121 to 192 cm
