Kubota L3750
Type: Compact Utility Tractors
Contents:
Production | |
| Manufacturer: | Kubota |
| Type: | Compact Utility tractor |
Variants | |
| L3750F: | 2WD |
| L3750DT: | 4WD |
Kubota L3750 Power | |
| Engine: | 45 hp 33.6 kW |
| PTO (claimed): | 37 hp 27.6 kW |
| Drawbar (tested): | 30.15 hp 22.5 kW |
| PTO (tested): | 36.96 hp 27.6 kW |
Mechanical | |
| Chassis: | 4x2 2WD (L3750F) |
| 4x4 MFWD 4WD | |
| Steering: | power |
| Brakes: | mechanical wet discs |
| Cab: | Two-post ROPS with optional sunshade. |
| Transmission: | 8-speed partially synchronized |
Capacity | |
| Fuel: | 15.3 gal 57.9 L |
| Hydraulic system: | 10.6 gal 40.1 L |
Hydraulics | |
| Type: | open center |
| Capacity: | 10.6 gal 40.1 L |
| Pressure: | 2500 psi 172.4 bar |
| Valves: | 0 to 2 |
| Pump flow: | 8.7 gpm 32.9 lpm |
Tractor hitch | |
| Rear Type: | I |
| Rear lift (at ends): | 3,525 lbs 1598 kg |
| Rear lift (at 24"/610mm): | 2,650 lbs 1202 kg |
Power Take-off (PTO) | |
| Rear PTO: | live |
| Rear RPM: | 540/750 |
Electrical | |
| Ground: | negative |
| Battery volts: | 12 |
Engine Detail | |
| Kubota F2302-D1-L | |
| diesel | |
| 5-cylinder | |
| liquid-cooled | |
| Displacement: | 142 ci 2.3 L |
| Bore/Stroke: | 3.3x3.2 inches 84 x 81 mm |
| Power: | 45 hp 33.6 kW |
| Air cleaner: | dual dry element |
| Rated RPM: | 2500 |
| Starter volts: | 12 |
| Oil capacity: | 12 qts 11.4 L |
| Coolant capacity: | 8 qts 7.6 L |
Transmission | |
| Type: | partially synchronized |
| Gears: | 8 forward and reverse |
| Clutch: | dual dry plates |
| Oil capacity: | 42.4 qts 40.1 L |
Dimensions | |
| Wheelbase: | 76.4 inches 194 cm |
| Length: | 128.5 inches 326 cm |
| Width: | 65.8 inches 167 cm |
| Height (steering wheel): | 60.2 inches 152 cm |
| Weight: | 3,650 lbs 1655 kg (L3750F) |
| 3,915 lbs 1775 kg (L3750DT) | |
| Front tread: | 48 to 72 inches 121 to 182 cm (2WD) |
| Front tread: | 52 inches 132 cm (4WD) |
| Rear tread: | 52 to 76 inches 132 to 193 cm |
