Kubota L1-215

Production: 1986 - 1988

Production
Manufacturer:	Kubota
Type:	Compact Utility tractor

Variants
L1-215DT:	4WD

Kubota L1-215 Power
Engine:	20.7 hp 15.4 kW

Mechanical
Chassis:	4x2 2WD
4x4 MFWD 4WD
Brakes:	wet disc
Cab:	Open operator station.
Transmission:	16-speed shuttle

Tractor hitch
Rear Type:	I

Power Take-off (PTO)
Rear RPM:	540/770/940/1250

Electrical
Ground:	negative
Battery volts:	12

Engine Detail
Kubota D1302
diesel
3-cylinder
liquid-cooled
Displacement:	79.3 ci 1.3 L
Bore/Stroke:	3.23x3.23 inches 82 x 82 mm
Power:	20.7 hp 15.4 kW
Rated RPM:	2500
Starter:	electric
Starter volts:	12

Transmission
Type:	shuttle
Gears:	16 forward and reverse
Clutch:	dry disc
Four gears in four ranges with shuttle shift.

Dimensions
Wheelbase:	59.1 inches 150 cm
Length:	113.8 inches 289 cm
Width:	49.4 inches 125 cm
Height:	54.7 inches 138 cm
2WD Weight:	2050 lbs 929 kg
4WD Weight:	2161 lbs 980 kg
2WD Ground clearance:	13.4 inches 34 cm
4WD Ground clearance:	10.8 inches 27 cm
2WD Front tread:	37.8 inches 96 cm
4WD Front tread:	37 inches 93 cm
Rear tread:	39/43.7 inches 99/110 cm
