Kubota KL48Z

Production: 2012 - 2015

Production
Manufacturer:	Kubota
Type:	Compact Utility tractor

Variants

wheeled

half-track

Kubota KL48Z Power
Engine:	47.3 hp 35.3 kW

Mechanical
Chassis:	4x4 MFWD 4WD
Steering:	power
Brakes:	mechanical wet disc
Cab:	Two-post ROPS. Cab optional with air-conditioning.
Transmissions:	continuously-varaible transmission
30-speed

Tractor hitch
Rear Type:	I

Power Take-off (PTO)
Rear RPM:	540 (1.375)
Engine RPM:	561@2700 795@2700 997@2700 1336@2700 -792@2700

Electrical
Ground:	negative
Battery volts:	12

Engine Detail
Kubota V2403
diesel
4-cylinder
liquid-cooled
Displacement:	148.5 ci 2.4 L
Bore/Stroke:	3.43x4.03 inches 87 x 102 mm
Power:	47.3 hp 35.3 kW
Rated RPM:	2700
Starter:	electric
Starter volts:	12

Dimensions
Wheelbase:	76.4 inches 194 cm
Length:	136.8 inches 347 cm
Width:	61 inches 154 cm
Height (ROPS):	93.3 inches 236 cm
Height (cab):	90.6 inches 230 cm
Weight:	4233 lbs 1920 kg
Ground clearance:	17.3 inches 43 cm
Front tread:	47.8 inches 121 cm
Rear tread:	47.6 to 56.3 inches 120 to 143 cm
