Kubota KL385

Production: 2008 - 2009

Production
Manufacturer:	Kubota
Type:	Compact Utility tractor

Variants

standard

high-speed

Kubota KL385 Power
Engine:	37.4 hp 27.9 kW

Mechanical
Chassis:	4x4 MFWD 4WD
Steering:	power
Brakes:	mechanical wet disc
Cab:	Two-post ROPS. Cab optional.
Transmission:	24-speed

Tractor hitch
Rear Type:	I

Power Take-off (PTO)
Rear RPM:	540 (1.375)
Engine RPM:	540@2600 762@2600 944@2600 1258@2600 -944@2600

Electrical
Ground:	negative
Battery volts:	12

Engine Detail
Kubota V2203
diesel
4-cylinder
liquid-cooled
Displacement:	134.1 ci 2.2 L
Bore/Stroke:	3.43x3.64 inches 87 x 92 mm
Power:	37.4 hp 27.9 kW
Rated RPM:	2600
Starter:	electric
Starter volts:	12

Transmission
Gears:	24 forward and 16 reverse
Twelve gears in two ranges (creeper and high) with shuttle shift. Only eight gears available in reverse.

Dimensions
Wheelbase:	74.4 inches 188 cm
Length:	125.2 inches 318 cm
Width:	58.9 inches 149 cm
Height (ROPS):	91.3 inches 231 cm
Height (cab):	86.6 inches 219 cm
ROPS Weight:	3351 lbs 1520 kg
Cab Weight:	3781 lbs 1715 kg
Ground clearance:	15.8 inches 40 cm
Front tread:	47.2 inches 119 cm
Rear tread:	44.9/56.3 inches 114/143 cm
