Kubota KL2850-PC

Production: 2010 - 2011

Production
Manufacturer:	Kubota
Type:	Half-track Crawler tractor

Kubota KL2850-PC Power
Engine:	27.6 hp 20.6 kW

Mechanical
Chassis:	half-track
Steering:	power
Brakes:	mechanical wet disc
Cab:	Two-post ROPS. Cab optional with air-conditioning.
Transmission:	24-speed

Tractor hitch
Rear Type:	I

Power Take-off (PTO)
Rear RPM:	540 (1.375)
Engine RPM:	561@2700 791@2700 980@2700 1307@2700 -980@2700

Electrical
Ground:	negative
Battery volts:	12

Engine Detail
Kubota D1703
diesel
3-cylinder
liquid-cooled
Displacement:	100.5 ci 1.6 L
Bore/Stroke:	3.4x3.6 inches 86 x 91 mm
Power:	27.6 hp 20.6 kW
Rated RPM:	2700
Starter:	electric
Starter volts:	12

Transmission
Gears:	24 forward and 16 reverse
Clutch:	dry disc

Dimensions
Wheelbase:	65.8 inches 167 cm
Length:	127 inches 322 cm
Width:	62.2 inches 157 cm
Height (ROPS):	80.1 inches 203 cm
Height (cab):	86.2 inches 218 cm
ROPS Weight:	3384 lbs 1534 kg
Cab Weight:	3748 lbs 1700 kg
Ground clearance:	15.6 inches 39 cm
Front tread:	42.7 inches 108 cm
Rear tread:	46.5 inches 118 cm
