Kubota KL2450

Production: 2010 - 2011

Production
Manufacturer:	Kubota
Type:	Compact Utility tractor

Kubota KL2450 Power
Engine:	23.6 hp 17.6 kW

Mechanical
Chassis:	4x4 MFWD 4WD
Steering:	power
Brakes:	mechanical wet disc
Cab:	Two-post ROPS. Cab optional with air-conditioning.
Transmissions:	16-speed
16-speed power shift
24-speed
30-speed

Tractor hitch
Rear Type:	I

Power Take-off (PTO)
Rear RPM:	540 (1.375)
Engine RPM:	541@2700 760@2700 945@2700 1260@2700 -945@2700

Electrical
Ground:	negative
Battery volts:	12

Engine Detail
Kubota D1503
diesel
3-cylinder
liquid-cooled
Displacement:	91.5 ci 1.5 L
Bore/Stroke:	3.27x3.64 inches 83 x 92 mm
Power:	23.6 hp 17.6 kW
Rated RPM:	2700
Starter:	electric
Starter volts:	12

Dimensions
ROPS Wheelbase:	61 inches 154 cm
Cab Wheelbase:	63 inches 160 cm
ROPS Length:	116.7 inches 296 cm
Cab Length:	118.7 inches 301 cm
ROPS Width:	49 inches 124 cm
Cab Width:	53.2 inches 135 cm
Height (ROPS):	78.4 inches 199 cm
Height (cab):	80.5 inches 204 cm
ROPS Weight:	2557 lbs 1159 kg
Cab Weight:	3031 lbs 1374 kg
Ground clearance:	13.8 inches 35 cm
Front tread:	38.2 inches 97 cm
Rear tread:	39.8/40.6 inches 101/103 cm
