Kubota GL417

Production: 1996 - 2001

Production
Manufacturer:	Kubota
Type:	Compact Utility tractor

Kubota GL417 Power
Engine:	41.4 hp 30.9 kW
PTO (claimed):	37.8 hp 28.2 kW

Mechanical
Chassis:	4x4 MFWD 4WD
Steering:	power
Brakes:	mechanical wet disc
Cab:	Two-post ROPS. Cab optional.
Transmissions:	16-speed gear
16-speed power shift

Hydraulics
Pump flow:	6.3 gpm 23.8 lpm

Tractor hitch
Rear Type:	I
Rear lift:	1907 lbs 865 kg

Power Take-off (PTO)
Rear RPM:	544/806/1252 (1.375)

Electrical
Ground:	negative
Battery volts:	12

Engine Detail
Kubota V2203
diesel
4-cylinder
liquid-cooled
Displacement:	134.1 ci 2.2 L
Bore/Stroke:	3.425x3.638 inches 87 x 92 mm
Power:	41.4 hp 30.9 kW
Rated RPM:	2600
Starter:	electric
Starter volts:	12

Dimensions
Wheelbase:	72.1 inches 183 cm
Length:	130.9 inches 332 cm
Width:	58.7 inches 149 cm
Height (ROPS):	85.6 inches 217 cm
Height (cab):	84.8 inches 215 cm
ROPS Weight:	3175 lbs 1440 kg
Cab Weight:	3616 lbs 1640 kg
Ground clearance:	14.2 inches 36 cm
Front tread:	44.5 inches 113 cm
Rear tread:	45.5 to 57 inches 115 to 144 cm
