Kioti PX1053

Production: 2016

Production
Manufacturer:	Kioti (a part of Daedong)
Type:	Utility tractor

Kioti PX1053 Power
Engine (gross):	103 hp 76.8 kW
PTO (claimed):	86.6 hp 64.6 kW

Mechanical
Chassis:	4x4 MFWD 4WD
Steering:	power
Brakes:	wet disc
Cab:	Cab standard with air-conditioning.
Transmission:	32-speed power shuttle

Hydraulics
Type:	open center
Pump flow:	31.5 gpm 119.2 lpm

Tractor hitch
Rear Type:	II
Control:	position and draft control
Rear lift (at 24"/610mm):	8002 lbs 3629 kg

Power Take-off (PTO)
Rear PTO:	independent
Rear RPM:	540/1000

Electrical
Ground:	negative
Charging system:	alternator
Battery volts:	12

Engine Detail
Doosan DL03-LEA08
turbocharged diesel
4-cylinder
liquid-cooled inline
Displacement:	208 ci 3.4 L
Bore/Stroke:	3.86x4.45 inches 98 x 113 mm
Power (gross):	103 hp 76.8 kW
Rated RPM:	2200
Starter:	electric
Starter volts:	12

Transmission
Type:	power shuttle
Gears:	32 forward and reverse
Clutch:	wet disc

Dimensions
Wheelbase:	93.3 inches 236 cm
Length:	168.9 inches 429 cm
Width:	88.6 inches 225 cm
Height (cab):	107.9 inches 274 cm
Weight:	9064 lbs 4111 kg
Ground clearance:	19.5 inches 49 cm
