John Deere 7515

Production: 2005 - 2010

Production
Manufacturer:	John Deere
Type:	Utility tractor
Factory:	Montenegro, Brazil

John Deere 7515 Power
Engine:	140 hp 104.4 kW
PTO (claimed):	119 hp 88.7 kW

Mechanical
Chassis:	4x4 MFWD 4WD
Differential lock:	electro-hydraulic
Steering:	hydrostatic power
Brakes:	hydraulic wet disc
Cab:	Cab optional.
Transmission:	16-speed partial power shift

Capacity
Fuel:	81 gal 306.6 L
Hydraulic system:	16.9 gal 64.0 L
Front axle:	8.7 qts 8.2 L
Front hubs:	1.8 qts 1.7 L (each)

Hydraulics
Type:	closed-center load sensing
Capacity:	16.9 gal 64.0 L
Pressure:	2756 psi 190.0 bar
Valves:	2 to 3
Pump flow:	26.4 gpm 99.9 lpm
SCV flow:	25.4 gpm 96.1 lpm
Oil type:	JD Hy-Gard

Tractor hitch
Rear Type:	II
Control:	electronic lower link
Rear lift (at ends):	10,690 lbs 4848 kg
Rear lift (at 24"/610mm):	6,500 lbs 2948 kg

Power Take-off (PTO)
Rear PTO:	independent
Clutch:	electro-hydraulic
Rear RPM:	540/1000

Electrical
Ground:	negative
Charging system:	alternator
Charging amps:	90
Battery volts:	12
Battery AH:	150

Engine Detail
John Deere 6068T Series 350
turbocharged diesel
6-cylinder
liquid-cooled
Displacement:	414.4 ci 6.8 L
Bore/Stroke:	4.19x5.00 inches 106 x 127 mm
Power:	140 hp 104.4 kW
Rated RPM:	2100
Torque:	449.9 lb-ft 610.1 Nm
Torque RPM:	1500
Starter volts:	12
Coolant capacity:	26.4 qts 25.0 L

Transmission
Transmission:	John Deere PowrQuad
Type:	partial power shift
Gears:	16 forward and reverse
Clutch:	hydraulic wet disc PermaClutch II
Oil capacity:	67.6 qts 64.0 L
Oil type:	JD Hy-Gard

Dimensions
Wheelbase:	104.3 inches 264 cm
Length:	195.6 inches 496 cm
Height:	112 inches 284 cm
Max weight:	17,640 lbs 8001 kg
Rear axle:	Rack-and-pinion
Front tread:	63.6 to 84.8 inches 161 to 215 cm
Rear tread:	62.4 to 75.7 inches 158 to 192 cm
