John Deere 4650
Type: Row-crop Tractors
Contents:
Production | |
| Manufacturer: | John Deere |
| Type: | Row-Crop tractor |
| Factory: | Waterloo, Iowa, USA |
| Original price: | $62,000 (1988 ) |
John Deere 4650 Power | |
| Drawbar (claimed): | 137 hp 102.2 kW |
| PTO (claimed): | 165 hp 123.0 kW |
| Drawbar (tested): | 142.31 hp 106.1 kW |
| PTO (tested): | 165.70 hp 123.6 kW |
Mechanical | |
| Chassis: | 4x2 2WD |
| 4x4 MFWD 4WD | |
| Final drives: | inboard planetary |
| Differential lock: | hydraulic rear |
| Steering: | power |
| Brakes: | hydraulic wet disc |
| Cab: | Sound-Gard cab standard. Optional four-post Roll-Gard ROPS. |
| Transmissions: | 16-speed partial power shift |
| 15-speed full power shift | |
Capacity | |
| Fuel: | 102 gal 386.1 L |
| Hydraulic system: | 18.6 gal 70.4 L (2WD Power Shift) |
| 21.6 gal 81.8 L (4WD Power Shift) | |
| 26.9 gal 101.8 L (Quad-Range) | |
Hydraulics | |
| Type: | closed center |
| Capacity: | 18.6 gal 70.4 L (2WD Power Shift) |
| 21.6 gal 81.8 L (4WD Power Shift) | |
| 26.9 gal 101.8 L (Quad-Range) | |
| Pressure: | 2277 psi 157.0 bar |
| Valves: | 2 or 3 |
| Pump flow: | 29.5 gpm 111.7 lpm |
Tractor hitch | |
| Rear Type: | III |
| Control: | lower-link draft sensing |
| Rear lift: | 8,475 lbs 3844 kg |
Power Take-off (PTO) | |
| Rear PTO: | independent |
| Clutch: | hydraulic wet disc |
| Rear RPM: | 1000 |
| Engine RPM: | 1000@2200 |
4650 Serial Numbers | |
| Location: | Differential on rear of tractor. |
| 1983: | 1000 |
| 1984: | 7001 |
| 1985: | 10001 |
| 1986: | 12501 |
| 1987: | 14001 |
| 1988: | 15501 |
| 1989: | 17501 |
Electrical | |
| Ground: | negative |
| Charging system: | alternator |
| Charging amps: | 72 |
| 90 (with Sound-Gard cab) | |
| Batteries: | 2 |
| Battery volts: | 6 |
| 12*Optional | |
Engine Detail | |
| John Deere | |
| intercooled turbocharged diesel | |
| 6-cylinder | |
| liquid-cooled | |
| Displacement: | 466 ci 7.6 L |
| Bore/Stroke: | 4.56x4.75 inches 116 x 121 mm |
| Air cleaner: | dry |
| Compression: | 15.8:1 |
| Rated RPM: | 2200 |
| Firing order: | 1-5-3-6-2-4 |
| Starter volts: | 12 |
| Oil capacity: | 21 qts 19.9 L |
| Coolant capacity: | 32 qts 30.3 L |
Dimensions | |
| Wheelbase: | 118.5 inches 300 cm (2WD) |
| 117.1 inches 297 cm (4WD) | |
| Length: | 179.7 inches 456 cm (2WD) |
| 184.8 inches 469 cm (4WD) | |
| Width: | 118 inches 299 cm (standard axle) |
| 96 inches 243 cm (optional axle) | |
| 108 inches 274 cm (optional axle) | |
| Height: | 117.8 inches 299 cm |
| Shiping weight: | 16,685 lbs 7568 kg |
| Operating weight: | 18,585 lbs 8430 kg (2WD Power Shift) |
| Ground clearance: | 14.92 inches 37 cm |
| Rear axle: | Rack-and-pinion: 3.94 by 96 inches 100 by 2438 mm |
| Rear axle: | Rack-and-pinion: 3.94 by 108 inches 100 by 2743 mm |
| Rear axle: | Rack-and-pinion: 3.94 by 118 inches 100 by 2997 mm |
