John Deere 3300

Production: 1995 - 1998

Production
Distributor:	John Deere
Manufacturer:	Renault
Type:	Utility tractor
Factory:	Le Mans, France

John Deere 3300 Power
Engine (net):	75 hp 55.9 kW

Mechanical
Chassis:	4x2 2WD
4x4 MFWD 4WD
Steering:	power
Brakes:	wet disc
Cab:	Cab standard with heater. Optional deluxe X Cab.
Transmissions:	10-speed synchronized
20-speed synchronized
20-speed two-speed power shift

Hydraulics
Type:	open center
Pressure:	2611 psi 180.0 bar
Pump flow:	13.7 gpm 51.9 lpm
Steering flow:	7 gpm 26.5 lpm

Tractor hitch
Rear Type:	II
Control:	lower-link draft sensing
Rear lift:	8430 lbs 3823 kg
10071 lbs 4568 kg *Optional

Power Take-off (PTO)
Rear PTO:	independent
3300 Clutch:	mechanical
3300X Clutch:	hydraulic
Rear RPM:	540/540E
540/1000*Optional

Electrical
Ground:	negative
Charging system:	alternator
Charging amps:	65
Battery volts:	12
Battery AH:	105

Engine Detail
John Deere 4045D
diesel
4-cylinder
liquid-cooled
Displacement:	276 ci 4.5 L
Bore/Stroke:	4.19x5.00 inches 106 x 127 mm
Rated Power (ECE R24):	75 hp 55.9 kW
Rated RPM:	2050
Torque:	210 lb-ft 284.8 Nm
Torque RPM:	1500
Starter:	electric
Starter volts:	12

Dimensions
Width:	73.2 inches 185 cm
3300 Height (cab):	97.8 inches 248 cm
3300X Height (cab):	104.9 inches 266 cm
Shiping weight:	7672 lbs 3480 kg
