Iseki AT370

Production: 2010 - 2012

Production
Manufacturer:	Iseki
Type:	Compact Utility tractor

Iseki AT370 Power
Engine:	36.5 hp 27.2 kW

Mechanical
Chassis:	4x4 MFWD 4WD
Steering:	power
Brakes:	wet disc
Cab:	Two-post ROPS. Cab optional with air-conditioning.
Transmission:	24-speed

Tractor hitch
Rear Type:	I

Power Take-off (PTO)
Rear RPM:	540 (1.375)
Engine RPM:	586@2500 787@2500 970@2500 1263@2500 -787@2500

Electrical
Ground:	negative
Battery volts:	12

Engine Detail
Iseki E4CG
diesel
4-cylinder
liquid-cooled
Displacement:	134.1 ci 2.2 L
Bore/Stroke:	3.425x3.64 inches 87 x 92 mm
Power:	36.5 hp 27.2 kW
Rated RPM:	2500
Starter:	electric
Starter volts:	12

Transmission
Gears:	24 forward and reverse
Clutch:	dry disc

Dimensions
Wheelbase:	76 inches 193 cm
Length:	139.8 inches 355 cm
Width:	60.4 inches 153 cm
Height (ROPS):	100 inches 254 cm
Height (cab):	89 inches 226 cm
ROPS Weight:	3726 lbs 1690 kg
Cab Weight:	4079 lbs 1850 kg
Ground clearance:	14 inches 35 cm
Front tread:	49.6 inches 125 cm
Rear tread:	44.9 to 59.1 inches 114 to 150 cm
