Iseki AT340

Production: 2010 - 2012

Production
Manufacturer:	Iseki
Type:	Compact Utility tractor

Variants

wheeled

half-track

Iseki AT340 Power
Engine:	33.5 hp 25.0 kW

Mechanical
Chassis:	4x4 MFWD 4WD
Steering:	power
Brakes:	wet disc
Cab:	Two-post ROPS. Cab optional with air-conditioning.
Transmissions:	16-speed
24-speed

Tractor hitch
Rear Type:	I

Power Take-off (PTO)
Rear RPM:	540 (1.375)
Engine RPM:	592@2600 795@2600 980@2600 1276@2600 -795@2600

Electrical
Ground:	negative
Battery volts:	12

Engine Detail
Iseki E3CG
diesel
3-cylinder
liquid-cooled
Displacement:	100.5 ci 1.6 L
Bore/Stroke:	3.43x3.62 inches 87 x 92 mm
Power:	33.5 hp 25.0 kW
Rated RPM:	2600
Starter:	electric
Starter volts:	12

Dimensions
Wheelbase:	68.1 inches 172 cm
Length:	122.4 inches 310 cm
Width:	55.7 inches 141 cm
Height (ROPS):	80.9 inches 205 cm
Height (cab):	78.5 inches 199 cm
ROPS Weight:	3042 lbs 1379 kg
Cab Weight:	3362 lbs 1525 kg
Ground clearance:	14.8 inches 37 cm
Front tread:	45.3 inches 115 cm
Rear tread:	43.3 to 55.9 inches 109 to 141 cm
