International Harvester DGD-4

Production: 1953 - 1956

Production
Manufacturer:	International Harvester
Type:	Row-Crop tractor
Factory:	Neuss, Germany
Total built:	8,130

International Harvester DGD-4 Power
Engine:	30 hp 22.4 kW

Mechanical
Chassis:	4x2 2WD
Differential lock:	mechanical rear
Brakes:	disc
Cab:	Open operator station.
Transmission:	5-speed gear

Tractor hitch
Rear Type:	II/I

Power Take-off (PTO)
Rear RPM:	540 (1.375)

Engine Detail
International Harvester DD-132
diesel
4-cylinder
liquid-cooled
Displacement:	132.7 ci 2.2 L
Bore/Stroke:	3.252x4.00 inches 83 x 102 mm
Power:	30 hp 22.4 kW
Compression:	19:1
Rated RPM:	1750
Starter volts:	12
Oil capacity:	6.9 qts 6.5 L
Coolant capacity:	13.7 qts 13.0 L

Transmission
Type:	gear
Gears:	5 forward and 1 reverse

Dimensions
Length:	111.5 inches 283 cm
Width:	64.25 inches 163 cm
Height:	52.25 inches 132 cm
Weight:	2855 lbs 1295 kg
Front tread:	49.25 to 80.75 inches 125 to 205 cm
Rear tread:	49.25 to 74.75 inches 125 to 189 cm
