International Harvester Cub
Contents:
Production | |
| Manufacturer: | International Harvester |
| Factory: | Louisville, Kentucky, USA |
| The International Cub's PTO ran counter-clockwise ("backwards") and at full engine speed, making it incompatible with standard PTO-driven equipment. In 1975 the "Increased Power" New International Cub was released. | |
International Harvester Cub Power | |
| Engine: | 13 hp 9.7 kW |
| Drawbar (claimed): | 10 hp 7.5 kW |
| PTO (claimed): | 11 hp 8.2 kW |
| Plows: | 1 (12 inch) |
Mechanical | |
| Chassis: | 4x2 2WD |
| Steering: | manual |
| Brakes: | differential mechanical drum |
| Cab: | Open operator station. |
| Transmission: | 3-speed sliding gear |
Capacity | |
| Fuel: | 7.5 gal 28.4 L |
| Hydraulic system: | 0.56 gal 2.1 L |
Hydraulics | |
| Capacity: | 0.56 gal 2.1 L |
| Pressure: | 1200 psi 82.7 bar |
| Total flow: | 2.8 gpm 10.6 lpm |
Tractor hitch | |
| Type: | IH Fast Hitch (optional) |
Power Take-off (PTO) | |
| Rear PTO: | independent |
| Rear RPM: | 1800 (counter-clockwise) |
Cub Serial Numbers | |
| Location: | Serial number plate on the right side of the Farmall Cub, above the front axle. |
| 1964: | 224704 |
| 1965: | 225110 |
| 1966: | 227209 |
| 1967: | 229225 |
| 1968: | 231005 |
| 1969: | 232981 |
| 1970: | 234868 |
| 1971: | 236827 |
| 1972: | 238506 |
| 1973: | 240581 |
| 1974: | 242746 |
| 1975: | 246561 |
| Final: | 248124 |
| 1975: | 248125 |
| 1976: | 248618 |
| 1977: | 250832 |
| 1978: | 252109 |
| 1979: | 253136 |
| Final: | 253685 |
Engine Detail | |
| International Harvester C60 | |
| gasoline | |
| 4-cylinder | |
| liquid thermosyphon-cooled | |
| Displacement: | 59.5 ci 1.0 L |
| Bore/Stroke: | 2.625x2.75 inches 67 x 70 mm |
| Power: | 13 hp 9.7 kW |
| Air cleaner: | oil bath |
| Compression: | 6.5:1 |
| Rated RPM: | 1800 |
| Firing order: | 1-3-4-2 |
| Starter volts: | 12 |
| Coolant capacity: | 9.75 qts 9.2 L |
| Sparkplug: | Champion D-21 |
| AC C86 | |
| Sparkplug gap: | 0.023 inches 0.584 mm |
| Intake valve clearance: | 0.013 inches 0.330 mm (cold) |
| Exhaust valve clearance: | 0.013 inches 0.330 mm (cold) |
Transmission | |
| Type: | sliding gear |
| Gears: | 3 forward and 1 reverse |
| Oil capacity: | 1.75 qts 1.7 L |
Dimensions | |
| Wheelbase: | 69.25 inches 175 cm |
| Length: | 99.325 inches 252 cm |
| Width: | 48.25 inches 122 cm |
| Height: | 62.75 inches 159 cm |
| Height (exhaust): | 76.25 inches 193 cm |
