International Harvester 946

Production: 1971 - 1977

Contents:

Production

Manufacturer:International Harvester
Factory:Neuss, Germany

International Harvester 946 Power

Engine:85 hp 63.4 kW

Mechanical

Chassis:4x2 2WD
4x4 MFWD 4WD optional
Transmissions:12-speed
16-speed

Hydraulics

Pump flow:10.0 gpm 37.9 lpm

Tractor hitch

Rear lift:6615 lbs 3000 kg

Power Take-off (PTO)

Rear RPM:540, 1000

Engine Detail

International Harvester
diesel
6-cylinder
liquid-cooled
Displacement:309.55 ci 5.1 L
Bore/Stroke:3.875x inches 98 x 111 mm 4.375
Power:85 hp 63.4 kW
Rated RPM:2100

Dimensions

Wheelbase:104.72 inches 265 cm
Length:157.48 inches 399 cm
Height:104.72 inches 265 cm
Weight:8489 lbs 3850 kg (9371 MFWD)
