International Harvester 734

Production: 1972 - 1974

Production
Manufacturer:	International Harvester
Type:	Row-Crop tractor

International Harvester 734 Power
Engine (gross):	73 hp 54.4 kW
Engine (net):	66.1 hp 49.3 kW
PTO (claimed):	61.7 hp 46.0 kW

Mechanical
Chassis:	4x2 2WD
4x4 MFWD 4WD
Final drives:	planetary
Differential lock:	mechanical rear
Steering:	manual
Steering:	power
Brakes:	disc
Cab:	Cab standard with optional heater.
Transmissions:	8-speed
12-speed

Tractor hitch
Rear Type:	II

Power Take-off (PTO)
Rear PTO:	independent
Rear RPM:	540/1000

Engine Detail
International Harvester D-239
diesel
4-cylinder
liquid-cooled
Displacement:	238.7 ci 3.9 L
Bore/Stroke:	3.87x5.06 inches 98 x 129 mm
Power (gross):	73 hp 54.4 kW
Fuel system:	direct injection
Compression:	16:1
Rated RPM:	2200
Torque:	185.2 lb-ft 251.1 Nm
Torque RPM:	1200
Starter:	electric
Starter volts:	12
Oil capacity:	9.5 qts 9.0 L
Coolant capacity:	20.6 qts 19.5 L

Dimensions
Wheelbase:	83.5 inches 212 cm
2WD Length:	131.5 inches 334 cm
4WD Length:	136.6 inches 346 cm
Width:	74.4 inches 188 cm
Height (steering wheel):	65 inches 165 cm
2WD Weight:	7477 lbs 3391 kg
4WD Weight:	8245 lbs 3739 kg
2WD Front tread:	51.6 to 70.1 inches 131 to 178 cm
4WD Front tread:	59.1 inches 150 cm
Rear tread:	57.5 to 77.2 inches 146 to 196 cm
