International Harvester 656

Production: 1965 - 1973

Production
Manufacturer:	International Harvester
Type:	Utility tractor
Original price:	$7,400 (1973 )

Variants
utility tractor
industrial tractor
row-crop tractor
656HC:	high-clear

International Harvester 656 Power
PTO (claimed):	63 hp 47.0 kW
Plows:	4-5

Mechanical
Chassis:	4x2 2WD
Cab:	Open operator station.
Transmissions:	5-speed sliding gear
10-speed two-speed power shift
hydrostatic

Hydraulics
Type:	open
Pump flow:	12 gpm 45.4 lpm

Tractor hitch
Rear Type:	2/1

Power Take-off (PTO)
Rear PTO:	independent
Rear RPM:	540/1000

656 Serial Numbers
Location:	Clutch housing, right side
1966:	7501 (IH)
1967:	7842 (IH)
1968:	9929 (IH)
1969:	11802 (IH)
1970:	13353 (IH)
1971:	14194 (IH)
1972:	14952 (IH)
1973:	15746 (IH)

Engine Detail
International Harvester C263
gasoline
6-cylinder
liquid-cooled
Displacement:	263 ci 4.3 L
Bore/Stroke:	3.5625x4.3906 inches 90 x 112 mm
Air cleaner:	dry
Coolant capacity:	20.5 qts 19.4 L

Dimensions
Wheelbase:	96.3 inches 244 cm
Weight:	6641 lbs 3012 kg
