Ford 3930

Production: 1990 - 2002

Production
Manufacturer:	Ford
Type:	Utility tractor
Factory:	Basildon, England
Original price:	$24,400 (1999 2WD )
Original price:	$29,900 (1999 4WD )

Ford 3930 Power
PTO (claimed):	45 hp 33.6 kW (early)
52 hp 38.8 kW (late)
Drawbar (tested):	38.18 hp 28.5 kW
PTO (tested):	52.54 hp 39.2 kW

Mechanical
Chassis:	4x2 2WD
4x4 MFWD 4WD
Steering:	power
Cab:	Two-post ROPS. Cab optional.
Transmissions:	8-speed
8-speed synchronized shuttle
16-speed partial power shift

Hydraulics
Type:	open center
closed center (optional)
Pressure:	2500 psi 172.4 bar
Valves:	0 to 2 (open center)
1 to 4 (closed center)
Pump flow:	7.7 gpm 29.1 lpm
12.8 gpm 48.4 lpm (optional)
Steering flow:	3.6 gpm 13.6 lpm

Tractor hitch
Rear Type:	2/1
Control:	position control with top link draft sensing
Rear lift:	3,080 lbs 1397 kg

Power Take-off (PTO)
Rear PTO:	independent
Rear RPM:	540
Engine RPM:	540@1800 540@1755 (shuttle)

3930 Serial Numbers
Location:	Upper right-hand side of transmission
1990:	BC26239
1991:	BC68791
1992:	BD05932
1993:	BD36207
1994:	BD63909
1995:	BD93327
1996:	021649B
1997:	056056B
1998:	083357B
1999:	111612B

Electrical
Ground:	negative
Charging system:	alternator
ROPS Charging amps:	55
Cab Charging amps:	70
Battery volts:	12

Engine Detail
Ford
diesel
3-cylinder
liquid-cooled
Original engine, used until 1995.
Displacement:	201 ci 3.3 L
Bore/Stroke:	4.40x4.40 inches 112 x 112 mm
Compression:	16.3:1
Rated RPM:	2000
Starter volts:	12

Dimensions
2WD Wheelbase:	84.5 inches 214 cm
4WD Wheelbase:	84.1 inches 213 cm
Length:	137 inches 347 cm
Height (ROPS):	91.3 inches 231 cm
Height (cab):	96 inches 243 cm
Operating weight:	5,446 lbs 2470 kg (4WD ROPS)
