Fiat 715
Type: Utility Tractors
Contents:
Production | |
| Manufacturer: | Fiat |
| Type: | Utility tractor |
Fiat 715 Power | |
| Engine: | 70 hp 52.2 kW |
Mechanical | |
| Chassis: | 4x2 2WD |
| 4x4 MFWD 4WD | |
| Brakes: | disc |
| Cab: | Open operator station. |
| Transmission: | 14-speed |
Tractor hitch | |
| Rear Type: | II |
| Rear lift: | 4409 lbs 1999 kg |
Power Take-off (PTO) | |
| Rear RPM: | 540 (1.375) |
| 1000 (1.375) | |
Engine Detail | |
| Fiat | |
| diesel | |
| 4-cylinder | |
| liquid-cooled | |
| Displacement: | 268.3 ci 4.4 L |
| Bore/Stroke: | 4.25x4.72 inches 108 x 120 mm |
| Power: | 70 hp 52.2 kW |
| Fuel system: | direct injection |
| Rated RPM: | 1900 |
Transmission | |
| Transmission: | Amplicouple |
| Gears: | 14 forward and 4 reverse |
| Seven gears forward, and two reverse, with two-speed power shift. | |
Dimensions | |
| 2WD Wheelbase: | 86.6 inches 219 cm |
| 4WD Wheelbase: | 81.9 inches 208 cm |
| Length: | 149.6 inches 379 cm |
| Ground clearance: | 18.5 inches 46 cm |
| 2WD Front tread: | 55.1 to 85 inches 139 to 215 cm |
| 4WD Front tread: | 66.9 inches 169 cm |
| Rear tread: | 55.1 to 78.7 inches 139 to 199 cm |
