Fiat 56-66S

Production: 1992 - 1996

Production
Manufacturer:	Fiat
Type:	Utility tractor

Fiat 56-66S Power
Engine:	54.3 hp 40.5 kW

Mechanical
Chassis:	4x2 2WD
4x4 MFWD 4WD
Steering:	power
Brakes:	wet disc
Cab:	Cab standard.
Transmissions:	12-speed gear
12-speed shuttle
20-speed creeper

Tractor hitch
Rear lift:	4685 lbs 2125 kg

Power Take-off (PTO)
Rear RPM:	540 (1.375)
540/750*Optional
540/1000*Optional

Electrical
Ground:	negative
Battery volts:	12

Engine Detail
Iveco 8035.06
diesel
3-cylinder
liquid-cooled
Displacement:	165.4 ci 2.7 L
Bore/Stroke:	3.94x4.53 inches 100 x 115 mm
Power:	54.3 hp 40.5 kW
Rated RPM:	2500
Starter:	electric
Starter volts:	12

Dimensions
2WD Wheelbase:	78.7 inches 199 cm
4WD Wheelbase:	74.9 inches 190 cm
2WD Length:	117.1 inches 297 cm
4WD Length:	116.9 inches 296 cm
2WD Weight:	4685 lbs 2125 kg
4WD Weight:	5236 lbs 2375 kg
2WD Ground clearance:	17.5 inches 44 cm
4WD Ground clearance:	13 inches 33 cm
2WD Front tread:	51.2 to 70.9 inches 130 to 180 cm
4WD Front tread:	54.5 to 71.6 inches 138 to 181 cm
Rear tread:	47.5 to 70.9 inches 120 to 180 cm
