Ferguson F-40
Type: Utility Tractors
Contents:
Production | |
| Manufacturer: | Ferguson |
| Type: | Utility tractor |
| Factory: | Detroit, Michigan, USA |
| The Ferguson F-40 is the same as the Massey Harris 50. The tractor was introduced during the dual line policy when the Massey-Harris-Ferguson company maintained separate Ferguson and Massey-Harris tractor lines. The F-40 was available as utility (S), single (T) or two-wheel (R) row-crop, and high-clearance (C) configurations. | |
Ferguson F-40 Power | |
| Drawbar (claimed): | 31 hp 23.1 kW |
| Belt (claimed): | 33 hp 24.6 kW |
| Plows: | 3 |
| Drawbar (tested): | 30.84 hp 23.0 kW |
| Belt (tested): | 32.80 hp 24.5 kW |
Mechanical | |
| Chassis: | 4x2 2WD |
| Steering: | manual |
| Steering: | power*Optional |
| Brakes: | differential mechanical shoe |
| Cab: | Open operator station. |
| Transmission: | 6-speed unsynchronized gear |
Capacity | |
| Fuel: | 17 gal 64.3 L |
| Hydraulic system: | 8 gal 30.3 L |
| Steering: | 1.6 qts 1.5 L |
Hydraulics | |
| Type: | open center |
| Capacity: | 8 gal 30.3 L |
| Pressure: | 1900 psi 131.0 bar |
| Steering flow: | 4 gpm 15.1 lpm |
| Steering cap.: | 1.6 qts 1.5 L |
Power Take-off (PTO) | |
| Rear PTO: | live |
| Rear RPM: | 540 (1.375) |
F-40 Serial Numbers | |
| Location: | Data plate on dashboard. |
| 1956: | 400001 |
| 1957: | 405671 |
| Final: | 409097 |
Electrical | |
| Charging system: | generator |
| Charging amps: | 10 |
| Battery volts: | 12 |
| Battery AH: | 50 |
Engine Detail | |
| Continental Z-134 | |
| gasoline | |
| 4.-cylinder | |
| liquid-cooled | |
| Displacement: | 134 ci 2.2 L |
| Bore/Stroke: | 3.3125x3.875 inches 84 x 98 mm |
| Air cleaner: | oil bath |
| Compression: | 6.6:1 |
| Rated RPM: | 2000 |
| Idle RPM: | 400-2200 |
| Starter volts: | 12 |
| Coolant capacity: | 10 qts 9.5 L |
| Sparkplug gap: | 0.025 inches 0.635 mm |
| Point gap: | 0.022 inches 0.559 mm |
| Intake valve clearance: | 0.015 inches 0.381 mm (cold) |
| Exhaust valve clearance: | 0.015 inches 0.381 mm (cold) |
Transmission | ||
| Type: | unsynchronized gear | |
| Gears: | 6 forward and 2 reverse | |
| Clutch: | dry disc | |
| Oil capacity: | 32 qts 30.3 L | |
| Oil type: | 50oF [10oC]↑ | : SAE 90 GL1 |
| 50oF [10oC]↓ | : SAE 80 GL1 | |
Dimensions | |
| Wheelbase: | 81.3 inches 206 cm |
| Length: | 120 inches 304 cm |
| Height: | 56.8 inches 144 cm |
| Operating weight: | 3419 lbs 1550 kg |
| Ballasted weight: | 5461 lbs 2477 kg |
| Clearance (front axle): | 20.3 inches 51 cm |
| Rear axle: | Flange |
| Front tread: | 48 to 80 inches 121 to 203 cm |
| Rear tread: | 48 to 76 inches 121 to 193 cm |
