Fendt 314 Vario
Type: Utility Tractors
Contents:
Production | |
| Manufacturer: | Fendt (a part of AGCO) |
| Type: | Utility tractor |
Fendt 314 Vario Power | |
| Engine (gross): | 130.1 hp 97.0 kW |
| Engine (max): | 150.2 hp 112.0 kW |
Mechanical | |
| Chassis: | 4x4 MFWD 4WD |
| Differential lock: | automatic front and rear differential lock |
| Steering: | power |
| Brakes: | wet disc |
| Trailer brakes: | hydraulic |
| Cab: | VisioPlus Cab standard with air-conditioning and suspension. Optional pneumatic cab suspension (Profi/Profi+). |
| Transmission: | continuously variable transmission |
Hydraulics | |
| Type: | open center |
| closed center*Optional | |
| Pressure: | 2900 psi 200.0 bar |
| Rear valves: | 2 to 4 |
| Front valves: | 1*Optional |
| Pump flow: | 22.2 gpm 84.0 lpm |
| 29.1 gpm 110.1 lpm (variable flow) | |
Tractor hitch | |
| Rear lift: | 13140 lbs 5960 kg |
| Front lift: | 6900 lbs 3129 kg |
Power Take-off (PTO) | |
| Rear PTO: | independent |
| Rear RPM: | 540/540E/1000 |
| Front PTO: | independent*Optional |
| Front RPM: | 1000 |
Electrical | |
| Ground: | negative |
| Charging system: | alternator |
| Battery volts: | 12 |
Engine Detail | |
AGCO Power | |
| turbocharged intercooled diesel | |
| 4-cylinder 16-valve | |
| liquid-cooled | |
| Displacement: | 268.4 ci 4.4 L |
| Bore/Stroke: | 4.25x4.72 inches 108 x 120 mm |
| Emissions: | Tier IV |
| Rated Power (ECE R120): | 130.1 hp 97.0 kW |
| Maximum Power (ECE R120): | 150.2 hp 112.0 kW |
| Rated RPM: | 2100 |
| Torque: | 479.4 lb-ft 650.1 Nm |
| Torque RPM: | 1500 |
| Starter: | electric |
| Starter volts: | 12 |
Transmission | |
| Transmission: | Vario ML75 |
| Type: | continuously variable transmission |
| Gears: | infinite forward and reverse |
Dimensions | |
| Wheelbase: | 95.3 inches 242 cm |
| Length: | 170.7 inches 433 cm |
| Width: | 91.3 inches 231 cm |
| Height (cab): | 112.6 inches 286 cm |
| Ground clearance: | 20.1 inches 51 cm |
| Front tread: | 71.7 inches 182 cm |
| Rear tread: | 70.9 inches 180 cm |
