Farmall Regular
Type: Row-crop Tractors
Contents:
Production | |
| Manufacturer: | Farmall (a part of International Harvester) |
| Type: | Row-Crop tractor |
| Factories: | Chicago, Illinois, USA |
| Rock Island, Illinois, USA | |
| Total built: | 134,650 |
Variants | |
| Fairway: | wide steel wheels for turf |
Farmall Regular Power | |
| Plows: | 2 |
| Drawbar (tested): | 13.27 hp 9.9 kW |
| Belt (tested): | 20.05 hp 15.0 kW |
Mechanical | |
| Chassis: | 4x2 2WD |
| Steering: | manual with automatic engagement of turning brakes |
| Cab: | Open operator's seat |
| Transmission: | 3-speed |
Power Take-off (PTO) | |
| Rear PTO: | transmission |
| Rear RPM: | 535 |
Regular Serial Numbers | |
| Location: | Tractor tool box. |
| 1924: | 501 |
| 1925: | 701 |
| 1926: | 1539 |
| 1927: | 5969 |
| 1928: | 15471 |
| 1929: | 40370 |
| 1930: | 75691 |
| 1931: | 117784 |
| 1932: | 131872 |
Engine Detail | |
| International Harvester | |
| gasoline | |
| 4-cylinder | |
| liquid-cooled vertical | |
| Displacement: | 220.9 ci 3.6 L |
| Bore/Stroke: | 3.75x5.00 inches 95 x 127 mm |
| Air cleaner: | oil bath and fiber |
| Rated RPM: | 1200 |
| Starter type: | hand crank |
| Coolant capacity: | 36 qts 34.1 L |
Transmission | |
| Gears: | 3 forward and 1 reverse |
Dimensions | |
| Length: | 136 inches 345 cm |
| Width: | 86 inches 218 cm |
| Height: | 67 inches 170 cm |
| Weight: | 4,000 lbs 1814 kg |
