Farmall A-514
Type: Row-crop Tractors
Contents:
Production | |
| Manufacturer: | Farmall (a part of International Harvester) |
| Type: | Row-Crop tractor |
| Factory: | Geelong, Australia |
| The McCormick International FARMALL A-514 was mechanically similar to the British-built B-450 and similar in appearance to the US-built 560. A row-crop tractor, it was available with single front wheel, tricycle front, or adjustable wide front. The A-514 was supplanted by the A-554. | |
Farmall A-514 Power | |
| Engine: | 50.5 hp 37.7 kW |
Mechanical | |
| Chassis: | 4x2 2WD |
| Steering: | manual |
| Cab: | Open operator station. |
| Transmission: | 5-speed gear |
Tractor hitch | |
| Rear Type: | II |
Engine Detail | |
| International Harvester AD-264 | |
| diesel | |
| 4-cylinder | |
| liquid-cooled | |
| Displacement: | 264 ci 4.3 L |
| Bore/Stroke: | 4.00x5.25 inches 102 x 133 mm |
| Power: | 50.5 hp 37.7 kW |
| Rated RPM: | 1450 |
| Starter type: | electric |
Transmission | |
| Type: | gear |
| Gears: | 5 forward and 1 reverse |
