Farm Pro 7510

Production: 2005 - 2012

Production
Distributor:	Farm Pro
Manufacturer:	Jinma
Factory:	China

Farm Pro 7510 Power
Engine:	75 hp 55.9 kW

Mechanical
Chassis:	4x4 MFWD 4WD
Steering:	power
Cab:	ROPS canopy
Transmission:	8-speed

Capacity
Fuel:	14.5 gal 54.9 L
Hydraulic system:	5.85 gal 22.1 L

Hydraulics
Capacity:	5.85 gal 22.1 L
Total flow:	9.30 gpm 35.2 lpm

Tractor hitch
Rear Type:	II
Rear lift (at 24"/610mm):	2,787 lbs 1264 kg

Power Take-off (PTO)
Rear RPM:	540

Engine Detail
diesel
4-cylinder
liquid-cooled
Displacement:	242.78 ci 4.0 L
Bore/Stroke:	4.13x4.92 inches 105 x 125 mm
Power:	75 hp 55.9 kW
Rated RPM:	2300
Oil capacity:	11.6 qts 11.0 L
Coolant capacity:	16.8 qts 15.9 L

Transmission
Gears:	8 forward and 2 reverse
Oil capacity:	50.5 qts 47.8 L

Dimensions
Wheelbase:	88.0 inches 223 cm
Length:	159.8 inches 405 cm
Width:	75.9 inches 192 cm
Height:	109.5 inches 278 cm
Shiping weight:	6,525 lbs 2959 kg
Operating weight:	7,032 lbs 3189 kg
Ground clearance:	13.4 inches 34 cm
