Erkunt Kiymet 90

Production: 2010

Production
Manufacturer:	Erkunt
Type:	Utility tractor
Factory:	Ankara, Turkey

Erkunt Kiymet 90 Power
Engine:	91.2 hp 68.0 kW

Mechanical
Chassis:	4x4 MFWD 4WD
Cab:	ROPS. Cab available with air-conditioning.
Transmission:	16-speed power shuttle

Hydraulics
Pressure:	2756 psi 190.0 bar
Valves:	4
Pump flow:	12.8 gpm 48.4 lpm

Tractor hitch
Rear lift:	8598 lbs 3900 kg

Power Take-off (PTO)
Rear PTO:	independent
Rear RPM:	430/540/540E/1000

Engine Detail
Perkins 1104D-44T
turbocharged intercooled diesel
4-cylinder
liquid-cooled
Displacement:	268.5 ci 4.4 L
Bore/Stroke:	4.13x5.00 inches 105 x 127 mm
Emissions:	Stage IIIA
Power:	91.2 hp 68.0 kW
Rated RPM:	2200
Torque:	289.9 lb-ft 393.1 Nm
Torque RPM:	1400
Starter type:	electric

Transmission
Type:	power shuttle
Gears:	16 forward and reverse

Dimensions
Wheelbase:	91.7 inches 232 cm
Length:	165.8 inches 421 cm
Width:	78.4 inches 199 cm
Height (ROPS):	108.3 inches 275 cm
Height (cab):	108.3 inches 275 cm
ROPS Weight:	8818 lbs 3999 kg
Cab Weight:	9480 lbs 4300 kg
Rear tread:	59.1 to 74.8 inches 150 to 189 cm
