Deutz-Fahr Agrotron 135

Production: 1997 - 2000
Type: Row-crop Tractors

Contents:

Production

Manufacturer:Deutz-Fahr
Type:Row-Crop tractor

Deutz-Fahr Agrotron 135 Power

Engine:135 hp 100.7 kW

Mechanical

Chassis:4x4 MFWD 4WD
Transmission:24-speed

Hydraulics

Pump flow:21.9 gpm 82.9 lpm

Tractor hitch

Rear lift:20374 lbs 9241 kg

Power Take-off (PTO)

Rear RPM:540, 1000

Engine Detail

Deutz BF6L1013E
turbocharged diesel
6-cylinder
Displacement:436 ci 7.1 L
Bore/Stroke:4.252x5.12 inches 108 x 130 mm
Power:135 hp 100.7 kW
Rated RPM:2300

Transmission

Gears:24 forward and reverse

Dimensions

Wheelbase:109.05 inches 276 cm
Length:105.51 inches 267 cm
Height:116.5 inches 295 cm
Weight:11818 lbs 5360 kg
