Deutz-Fahr AgroStar 4.68

Production: 1993 - 1995

Contents:

Production

Manufacturer:Deutz-Fahr

Deutz-Fahr 4.68 Power

Engine:91 hp 67.9 kW

Mechanical

Chassis:4x4 MFWD 4WD
Steering:power
Brakes:dry disc
Cab:Cab standard.
Transmission:48-speed

Hydraulics

Pump flow:12.4 gpm 46.9 lpm

Tractor hitch

Rear Type:II
Rear lift:11245 lbs 5100 kg

Power Take-off (PTO)

Rear RPM:540/1000

Engine Detail

Deutz BF4L 913
turbocharged diesel
4-cylinder
air-cooled
Displacement:249.3 ci 4.1 L
Bore/Stroke:3.94x4.84 inches 100 x 123 mm
Power:91 hp 67.9 kW
Rated RPM:2300

Transmission

Gears:48 forward and 12 reverse
Clutch:dry disc
Six gears in four ranges with two-speed high-low shift.

Dimensions

Wheelbase:96.5 inches 245 cm
Length:176.5 inches 448 cm
Height:109.1 inches 277 cm
Weight:9261 lbs 4200 kg
