Deutz F1L514 50

Production: 1950 - 1957

Production
Manufacturer:	Deutz
Factory:	Germany

Deutz F1L514 Power
Engine:	14.8 hp 11.0 kW

Mechanical
Chassis:	4x2 2WD
Steering:	manual
Cab:	Open operator station.
Transmission:	4-speed gear

Power Take-off (PTO)
Rear RPM:	540 (1.375)

Engine Detail
Deutz
diesel
1-cylinder
air-cooled
Displacement:	81.2 ci 1.3 L
Bore/Stroke:	4.33x5.51 inches 110 x 140 mm
Power:	14.8 hp 11.0 kW
Rated RPM:	1650
Starter:	electric
Starter volts:	12

Dimensions
Wheelbase:	62.4 inches 158 cm
Length:	98.8 inches 250 cm
Width:	63 inches 160 cm
Height:	60.6 inches 153 cm
Weight:	2833 lbs 1285 kg
Ground clearance:	15.8 inches 40 cm
Rear tread:	49.2 to 59.1 inches 124 to 150 cm
