Deutz D 5505

Production: 1965 - 1966

Production
Manufacturer:	Deutz

Deutz D 5505 Power
Engine:	52 hp 38.8 kW

Mechanical
Transmission:	8-speed

Hydraulics
Pump flow:	7.1 gpm 26.9 lpm

Tractor hitch
Rear lift:	4851 lbs 2200 kg

Power Take-off (PTO)
Rear RPM:	540, 1000

Engine Detail
Deutz
diesel
4-cylinder
Displacement:	207.47 ci 3.4 L
Bore/Stroke:	3.74x4.72 inches 95 x 120 mm
Power:	52 hp 38.8 kW
Rated RPM:	2300

Transmission
Gears:	8 forward and 4 reverse

Dimensions
Wheelbase:	86.61 inches 219 cm
Length:	146.85 inches 372 cm
Height:	70.47 inches 178 cm
Weight:	5380 lbs 2440 kg
