Deere 6325
Type: Utility Tractors
Contents:
Production | |
| Manufacturer: | John Deere |
| Type: | Utility tractor |
| Factory: | Mannheim, Baden-Württemberg, Germany |
John Deere 6325 Power | |
| Engine (gross): | 105 hp 78.3 kW |
| Engine (net): | 100 hp 74.6 kW |
| Engine (max): | 109 hp 81.3 kW |
| PTO (claimed): | 88 hp 65.6 kW |
Mechanical | |
| Chassis: | 4x2 2WD |
| 4x4 MFWD 4WD (optional) | |
| Steering: | hydrostatic power |
| Brakes: | hydraulic wet disc |
| Cab: | Two-post foldable ROPS. |
| Transmissions: | 12-speed synchronized |
| 16-speed power shuttle | |
Hydraulics | |
| Type: | open center gear pump |
| Pressure: | 2538 psi 175.0 bar |
| Pump flow: | 14.27 gpm 54.0 lpm |
Tractor hitch | |
| Rear Type: | 2/1 |
| Control: | load and depth control with mechanical top-link sensing |
| Rear lift: | 9,037 lbs 4099 kg |
Power Take-off (PTO) | |
| Rear PTO: | independent |
| Clutch: | mechanical-hydraulic wet disc |
| Rear RPM: | 540/1000 |
| Engine RPM: | 540@2143 1000@2208 |
6325 Serial Numbers | |
| Location: | Right side of main tractor frame. |
Electrical | |
| Ground: | negative |
| Charging system: | alternator |
| Charging amps: | 90 |
| Battery volts: | 12 |
| Battery AH: | 110 |
Engine Detail | |
| John Deere 4045HL | |
| turbocharged intercooled diesel | |
| 4-cylinder | |
| liquid-cooled | |
| Displacement: | 276 ci 4.5 L |
| Bore/Stroke: | 4.19x5.00 inches 106 x 127 mm |
| Emissions: | Stage III |
| Rated Power (ECE R24): | 100 hp 74.6 kW |
| Rated Power (EC 97/98): | 105 hp 78.3 kW |
| Maximum Power (ECE R24): | 105 hp 78.3 kW |
| Maximum Power (EC 97/68): | 109 hp 81.3 kW |
| Fuel system: | electronic fuel injection |
| Cooling system: | viscous fan |
| Rated RPM: | 2300 |
| Idle RPM: | 850-2460 |
| Operating RPM: | 1500-2300 |
| Torque: | 319 lb-ft 432.6 Nm |
| Torque RPM: | 1600 |
| Firing order: | 1-3-4-2 |
| Starter: | electric |
| Starter volts: | 12 |
| Oil capacity: | 16.9 qts 16.0 L |
| Coolant capacity: | 28 qts 26.5 L |
Dimensions | |
| Wheelbase: | 94.5 inches 240 cm |
| Length: | 168.2 inches 427 cm |
| Width: | 87.2 inches 221 cm |
| Height (ROPS): | 108.9 inches 276 cm |
| Shiping weight: | 8,333 lbs 3779 kg |
| Max weight: | 15,430 lbs 6999 kg |
| Clearance (rear axle): | 63.5,63.9,66.2,67.4,71.5,72.7,72.7,73.9,75.4 inches 161 cm |
| Rear axle: | Flange |
