Deere 6310SE

Production: 1998 - 2003

Production
Manufacturer:	John Deere
Type:	Utility tractor

John Deere 6310SE Power
Engine (net):	100 hp 74.6 kW

Mechanical
Chassis:	4x2 2WD
4x4 MFWD 4WD
Differential lock:	electro-hydraulic rear
Steering:	power
Brakes:	hydraulic wet disc
Trailer brakes:	hydraulic*Optional
pneumatic*Optional
Cab:	Cab standard with heat. Optional air-conditioning.
Transmissions:	12-speed synchronized
16-speed power shuttle
16-speed four-speed power shift

Capacity
Fuel:	43.6 gal 165.0 L
30.6 gal 115.8 L (LP Cab)
Hydraulic system:	14.5 gal 54.9 L

Hydraulics
Type:	load sensing
Capacity:	14.5 gal 54.9 L
Pressure:	2901 psi 200.0 bar
Valves:	4*Optional
Pump flow:	14.3 gpm 54.1 lpm

Tractor hitch
Rear Type:	II
Control:	electronic lower-link draft sensing
Rear lift:	10319 lbs 4680 kg

Power Take-off (PTO)
Rear PTO:	independent
Clutch:	electro-hydraulic wet disc
Rear RPM:	540
540/1000
540/540E/1000
Engine RPM:	540@2124 1000@2208 540E@1684
Front PTO:	independent
Clutch:	electro-hydraulic wet disc
Front RPM:	1000
Engine RPM:	1000@2185

6310SE Serial Numbers
Location:	Serial number plate on the right side of the tractors frame.

Electrical
Ground:	negative
Charging system:	alternator
Charging amps:	90
Battery volts:	12
Battery AH:	110

Engine Detail
John Deere
turbocharged diesel
4-cylinder
liquid-cooled
Displacement:	276.4 ci 4.5 L
Bore/Stroke:	4.19x5.00 inches 106 x 127 mm
Rated Power (ECE R24):	100 hp 74.6 kW
Cooling system:	viscous-drive fan
Air cleaner:	dry
Rated RPM:	2300
Torque:	297 lb-ft 402.7 Nm
Torque RPM:	1495
Starter:	electric
Starter volts:	12
Oil capacity:	12.7 qts 12.0 L
Coolant capacity:	14.3 qts 13.5 L

Dimensions
Wheelbase:	94.5 inches 240 cm
Length:	163.2 inches 414 cm
Width:	85.8 inches 217 cm
Height (cab):	104.1 inches 264 cm
99.9 inches 253 cm (LP Cab)
Shiping weight:	8924 lbs 4047 kg
Max weight:	17637 lbs 8000 kg
