Deere 2345F
Contents:
Production | |
| Distributor: | John Deere |
| Manufacturer: | Goldoni |
| Type: | Orchard/Vineyard tractor |
| Factory: | Italy |
John Deere 2345F Power | |
| Engine: | 66.1 hp 49.3 kW |
Mechanical | |
| Chassis: | 4x2 2WD |
| 4x4 MFWD 4WD | |
| Differential lock: | mechanical rear |
| Steering: | power |
| Brakes: | mechanical wet disc |
| Cab: | Two-post mid-mount folding ROPS. Quick-mount cab available. |
| Transmissions: | 8-speed synchronized |
| 16-speed creeper | |
Hydraulics | |
| Type: | open center |
| Pressure: | 2611 psi 180.0 bar |
| Rear valves: | 3 |
| Mid valves: | 3 |
| Pump flow: | 8.7 gpm 32.9 lpm |
| 17.4 gpm 65.9 lpm *Optional | |
Tractor hitch | |
| Rear Type: | IIN/I |
| Control: | top-link draft sensing |
| Rear lift (at 24"/610mm): | 3197 lbs 1450 kg |
Power Take-off (PTO) | |
| Rear PTO: | independent |
| Rear RPM: | 540/1000 (1.375) |
| Engine RPM: | 540@2165 540E@1624 |
Electrical | |
| Ground: | negative |
| Charging system: | alternator |
| Charging amps: | 35 |
| Battery volts: | 12 |
| Battery AH: | 100 |
Engine Detail | |
| John Deere | |
| turbocharged diesel | |
| 3-cylinder | |
| liquid-cooled | |
| Displacement: | 179.4 ci 2.9 L |
| Bore/Stroke: | 4.19x4.33 inches 106 x 110 mm |
| Power: | 66.1 hp 49.3 kW |
| Air cleaner: | dry |
| Rated RPM: | 2300 |
| Torque: | 180.7 lb-ft 245.0 Nm |
| Torque RPM: | 1500 |
| Starter: | electric |
| Starter volts: | 12 |
| Oil change: | 200 h |
Dimensions | |
| Wheelbase: | 72.2 inches 183 cm |
| Length: | 122.1 inches 310 cm |
| Width: | 51.7 inches 131 cm |
| 2WD Low-Profile Ground clearance: | 13.8 inches 35 cm |
| 4WD Low-Profile Ground clearance: | 9.5 inches 24 cm |
| 2WD High-Profile Ground clearance: | 17.7 inches 44 cm |
| 4WD High-Profile Ground clearance: | 14.6 inches 37 cm |
| 2WD Front tread: | 45.1 to 57 inches 114 to 144 cm |
| 4WD Front tread: | 44.3 to 58.9 inches 112 to 149 cm |
| Rear tread: | 39.3 to 58 inches 99 to 147 cm |
